Hepatocellular carcinoma (HCC) is the most common primary cancer of the liver. It usually develops in the setting of chronic liver disease, particularly viral hepatitis.1 The differential diagnosis of HCC versus metastatic carcinoma is clinically important because prognosis and treatment approaches vary.2–5

Currently, there are several diagnostic procedures to obtain pre-operative tissue diagnosis that guide subsequent therapy. Fine-needle aspiration cytology (FNAC) under image guidance has gained increasing acceptance as the diagnostic procedure of choice for patients with focal hepatic lesions. The diagnostic sensitivity of guided FNAC ranges between 67–100% and has a specificity of 93–100%. Alternatively, surgical procedures are invasive and often require general anesthesia and hospitalization.3,4 This is an important consideration in today’s climate of cost-conscious medical care.1,4 However, FNAC has its limitations, sampling is scanty and histological architecture is lost. The vast majority of malignancies in the liver are metastatic adenocarcinomas with a known or unknown primary. The majority (80%) of malignant liver lesions can be diagnosed on cytology combined with clinical correlation; however, 20% pose a diagnostic dilemma.6

Cell block preparation of liver aspirates is a useful adjunct to routine FNAC smears because multiple sections can be cut and immunohistochemistry stains and special stains can be applied, which can be of immense help in differentiating primary HCC from metastatic deposits in the liver. The gold standard for final diagnosis in difficult cases was Tru-cut biopsy.

We sought to evaluate the accuracy of FNAC in conjunction with cell blocks for diagnosing liver lesions. This requires a clinicopathological correlation considering the results of smear cytology with immunostaining.

Methods

Over two years, we prospectively studied 61 cases with space-occupying lesions (SOLs) of the liver that were clinically or radiologically suspicious for malignancy. Patients were referred to the Department of Cytopathology, Indraprastha Apollo Hospitals, New Delhi, for computed tomography (CT) or ultrasonography (USG) guided FNAC.

Cell block was sufficient for interpretation in 55 of the 61 cases.

Clinical details including history of pre-existing liver disease, biochemical data, serological markers, and radiological findings were recorded when available.

Fine-needle aspiration (FNA) was performed under ultrasound or CT guidance, using a 21–23 gauge lumbar puncture needle by the radiologist as an outpatient procedure. No local anesthesia was given.

Direct air-dried smears were prepared by a pathologist for routine Giemsa staining, and some smears were immediately fixed in 95% alcohol for Papanicolaou (Pap) staining. One smear of each sample was stained with Giemsa (Diff-Quick) for immediate assessment of the adequacy of the material aspirated and was examined under a microscope by a pathologist.

After preparing adequate smears, the remaining material in the syringe was allowed to clot. Once the aspirated material clotted, it was fixed in 10% neutral buffered formalin for four hours. The tissue was then processed overnight in an automated tissue processor along with other routine biopsies.

The block was trimmed and three-micron thick sections cut and stained with Giemsa, periodic acid-Schiff (PAS), and PAS with diastase. A final diagnosis was drawn after complete work up of the cases by the pathologist.

Statistical analysis using the chi-square and Fisher’s exact tests was done to compare various parameters in the patients. A p-value of ≤ 0.050 was considered significant.

Results

Sixty-one cases with liver SOLs, clinically or radiologically suspicious for malignancy, were referred to the Department of Cytopathology, Indraprastha Apollo Hospitals New Delhi for FNAC.

Following FNAC, six cases could not be interpreted by cell block due to either insufficient aspiration material for cell block formation, or scanty cellularity, crushed tumor cells, or blood only in the prepared cell blocks.

In the remaining 55 cases, clinico-radiological parameters, cytological features, cell block examination, and immunohistochemical features were studied. A histopathological biopsy confirmation was done in 14 (25.5%) cases.

The complete cytomorphological evaluation [Table 1] included study of cellularity, pattern of arrangement, cytoplasmic, and nuclear details. The useful cytological features in the diagnosis of HCC include trabecular pattern (p = 0.001) [Figure 1] with small capillaries traversing clusters of tumor cells [Figure 2], basket pattern (p = 0.005), benign hepatocytes (p = 0.000), hepatocytic appearance of tumor cells (p = 0.000), intracellular bile (p = 0.001) intranuclear inclusions (p = 0.000), macronucleoli (p = 0.000) [Figure 3] and atypical naked (stripped) nuclei (p = 0.015). In 10 (18.2%) cases, the cells had a very well differentiated cytomorphology and, therefore, it was not possible to give a definite diagnosis based on cytology alone. Similarly, in six (10.9%) cases the tumor cells were poorly differentiated and did not exhibit any particular differentiation. These cases would typically be reported as malignant. A final diagnosis was made using cell block preparation and immunocytochemistry. Use of a cell block helped in reaching a final diagnosis in an additional 16 (29.1%) cases.

There was a total of 10 (18.2%) very well differentiated cases, which were reticulin stained to determine the trabecular cord thickness [Figure 4]. In cases where the cord thickness was greater than three-cell thick, and there was a decrease in reticulin staining, a diagnosis of HCC was made. Based on these criteria, three (5%) cases were diagnosed as well-differentiated HCC and seven (13%) cases as regenerative lesions.

A follow-up biopsy was available in 14 (23.0%) of the 61 cases. Of these, 12 (85.7%) cases were consistent with the FNA diagnosis: only two cases (3.3%) were inconsistent. One was reported as no evidence of malignancy on FNA and as a neuroendocrine carcinoma on biopsy, and the other was reported as inadequate on FNA and as HCC on follow-up biopsy.

The age of our patients ranged from 32 to 90 years (mean = 58.8 years). The age of the patients with HCC ranged from 40 to 84 years (mean = 64.8 years). However, the age of the patients with metastatic carcinomas had a wider distribution ranging from 32 to 90 years (mean = 55.5 years). The female to male ratio was 4:6.

Out of the total 55 cases with cell blocks generated, the status of viral markers was available in 35 (63.6%) cases. We observed a clear predominance of hepatitis B virus (HBV) infection in cases of HCC. On the contrary, metastatic carcinomas did not show any association with viral markers.

The majority of patients with HCC as well as metastatic carcinomas were found to have solitary SOL on ultrasound/CT. Out of 15 HCC cases, 10 (66.6%) cases presented as solitary SOL of liver and this number was 19 (65.5%) of 29 in metastatic carcinomas. However, in the seven regenerative lesions, multiple SOLs were found to be more common (n = 4; 57.1%). The majority of HCC
(n = 13; 86.6%) and all regenerative lesions
(n = 7; 100.0%), diagnosed clinically and radiologically, arose in the background of cirrhosis. On the other hand, metastatic carcinomas were rarely seen to be present in cirrhotic livers
(n = 1; 3.4%).

Serum alpha-fetoprotein (AFP) levels were found to be >100 ng/ml in 10 (66.6%) HCC cases and one (14.3%) regenerative lesion case. None of the metastatic carcinomas showed significantly elevated serum AFP levels. However, a mildly elevated AFP level (up to 50 ng/ml) was seen in five (17.2%) cases of metastatic carcinoma. Thus, we concluded that although a mildly elevated AFP level can be seen in regenerative and metastatic carcinoma, a significantly raised serum AFP level is highly suggestive of an HCC. The history of a known primary was traced only in metastatic carcinomas (n = 11; 37.9%) cases.

Discussion

Early diagnosis of HCC is important because of the prognostic implications.7 A final diagnosis requires pathological confirmation.8–10 FNAC is a sufficiently accurate, simple, rapid, safe, and relatively painless and cost-effective technique, rendering it an attractive alternative to percutaneous biopsy.11

The various cytomorphological criteria described for diagnosing HCC are high cellularity, trabecular pattern, endothelial capping, basket pattern, traversing capillaries, atypical naked nuclei, cytoplasmic bile, atypical naked nuclei, intranuclear cytoplasmic inclusion, macronucleoli, and multiple nucleoli.12,13

Diagnosing HCC may be demanding to cytopathologists. Difficulties are attributed to the differentiation of well-differentiated HCC from regenerating hepatocytes and distinguishing HCC from metastatic carcinoma particularly if the tumor is poorly differentiated. Microhistology provides additional information regarding details such as trabecular-sinusoidal pattern, pseudoacini, unpaired arteries, and absent reticulin framework. Also, the cell blocks can be utilized for making multiple sections for special stains and immunohistochemistry procedures.14,15

The cytological features of HCC are well documented. Cohen et al,8 proposed that a high nuclear/cytoplasmic ratio, a trabecular arrangement pattern, and atypical naked nuclei are the three primary criteria for the diagnosis of HCC. In our study, these features were found in half of the HCC cases. In other studies, a trabecular pattern was seen predominantly.12,13 The frequency of intracytoplasmic bile was also found in 50% of cases in our study whereas the frequency of bile in liver aspirates in previous studies was from 17% to 68%.16

Differentiating poorly differentiated HCC from a poorly differentiated metastatic tumor is challenging. In our study, there were 29 (53%) cases of metastatic tumors of the liver: 25 were moderately differentiated, and four were poorly differentiated. AFP levels were not elevated in metastatic carcinoma cases.

Useful features for differentiating HCC from metastasis include trabecular pattern with small capillaries transgressing clusters of tumor cells, hepatocytic cells, bile pigment, intranuclear inclusions, and atypical stripped nuclei.

We used cell blocks to confirm the diagnosis of moderately differentiated (MD) metastatic carcinoma (n = 25; 41%) and MDHCC (n = 10; 18%) as determined by cytomorphology. Solid islands and trabeculae of hepatocytes thicker than three cells, rimmed by endothelial cells (i.e., basket pattern) was seen. This was confirmed with deficient or absent reticulin staining and further supported our diagnosis. In metastatic carcinoma, the cells had a cuboidal to columnar appearance and exhibited a glandular pattern.

In our study, well-differentiated HCC was found to have either deficient or absent reticulin, and regenerative nodules were found to have normal reticulin framework. The diagnosis of HCC in other studies was also supported by a cord thickness greater than three-cell thick and a decrease in reticulin staining or positive staining pattern outlining the trabeculae (greater than three-cell thick).14,17,18

Various studies demonstrated intracellular mucin present in metastasis and in none of the aspirates with benign or malignant hepatocytes, which is in agreement with our findings.14,16,19

In histologically normal adult human livers, Hep Par-1 detects an antigen localized to the hepatocyte cytoplasm. No staining of bile ducts or other non-parenchymal cells was seen. The pattern is distinctly granular, occasionally ring-like, and is present diffusely throughout the hepatocyte cytoplasm without canalicular accentuation.20 Positivity for Hep Par-1 and negativity for CK7/CK20 strongly favored HCC over metastasis, and negativity for Hep Par-1 and positivity for CK7/CK20 confirmed the diagnosis of metastasis. Six cases had poorly differentiated morphology. After immunohistochemical staining, a final diagnosis of poorly differentiated HCC was given in two (33.3%) cases, and four (67.0%) cases were diagnosed as poorly differentiated metastatic carcinoma. In one poorly differentiated case, reported as possible hepatocholangiocarcinoma, Hep Par-1 and CK7 was positive in the tumor cells, and polyclonal carcinoembryonic antigen (pCEA) and CK20 were negative.

In one study, Hep Par-1 was found to demonstrate 100% positivity in HCC compared to 0% and 15% positivity in cholangiocarcinoma and metastatic adenocarcinoma.19 pCEA was found to be specific for HCC but had poor sensitivity.19 However, in one study, 71% revealed canalicular staining with pCEA and was found to be confirming the diagnosis of HCC over metastatic adenocarcinoma.21

CK7 and CK20 were found to be useful for differentiating HCC from metastatic carcinoma, and to suggest possible primary malignancy.21

Hepatitis C virus (HCV) is the major etiological factor for HCC in the Mediterranean and South East Asia. In India, the prevalence of HCV-positive patients with HCC in previous studies was 4–10%.22 In our study the status of viral markers was available in 10 (66.7%) of the HCC diagnosed cases. Of these, six (60.0%) cases were positive for HBV and three (30.0%) cases were positive for HCV. In the regenerative lesions, the status of viral markers was available in five (71.4%) cases: three (60.0%) were positive for HBV, and only one case (20.0%) was positive for HCV. Out of the 20 (68.9%) metastatic carcinomas in which viral markers were available, a rare case of metastatic carcinoma was found to be positive for viral markers. This one case was seen in a patient with a preexisting HBV-associated chronic liver disease.

Serum AFP levels were found to be >100 ng/ml in 10 (66.7%) cases of HCC and one (14.3%) case of regenerative lesions. None of the metastatic carcinomas showed significantly elevated serum AFP levels. Thus, we concluded that a significantly raised serum AFP level is highly suggestive of an HCC, as was seen in other studies.16

The majority of patients with HCC as well as metastatic carcinomas were found to have solitary SOL on ultrasound and CT. Solitary SOL of liver was present in 10 (66.7%) HCCs and 19 (65.5%) metastatic carcinomas. However, in the regenerative lesions, multiple SOLs were found to be slightly more common (n = 4; 57.1%).

Conclusions

In our experience, difficulties in diagnosing SOL liver are attributed to differentiation of the tumor and cannot be performed using cytological smears alone. Cell block preparation gives an additional advantage as architectural details can be studied, multiple sections can be cut, and cytochemical stains and immunohistochemical markers can be applied. Therefore, we conclude that the use of the cell block technique should be used whenever sufficient material is obtained from needle aspirates of the liver lesions, which will help to reach an accurate diagnosis in problematic and challenging cases and increase the diagnostic yield and accuracy.

Disclosure

The authors declared no conflicts of interest. No funding was received for this study.
