Asphyxia (from the Greek words α “without” and sphyxis, “heartbeat”) is a condition of deficient tissue oxygenation leading to hypoxia with different etiologies. Traumatic asphyxia is a mechanical cause of hypoxia resulting from external compression and blunt thoracic trauma. It is also called crush asphyxia.1 Approximately 33% of blunt trauma patients have a thoracic injury and it is estimated that 25% of traumatic deaths are secondary to chest trauma.2

Excessive venous pressures cause the major manifestation of asphyxia, and the characteristic signs include facial and upper chest petechiae, subconjunctival hemorrhages, cervical cyanosis, and neurological signs due to cerebral edema and temporary loss of vision as a result of retinal edema. The venous hypertension in the valveless cervicofacial system results in the above findings.3

Treatment of traumatic asphyxia aims to maintain adequate tissue oxygenation and perfusion of the affected organs, and is directed towards the associated chest injuries (hemothorax, pneumothorax, fracture ribs, and pulmonary contusion) and other injuries; however, surgical intervention may be necessary. The primary concept of the management is based on the systemic nature of the insult, which needs careful assessment, and then general and specific treatments accordingly.

Case Report

A 39-year-old man presented to the emergency department at Saqr Hospital, UAE, with difficulty breathing, chest pain, and mental confusion after sustaining direct trauma to his thoracoabdominal region as he was stuck between two heavy solid objects for about five minutes at a construction site where he worked. Approximately 25 minutes elapsed before he was brought for medical care.

On examination, the patient was confused with an initial Glasgow Coma Scale (GCS) of 14. He had rapid shallow breathing and bilateral massive subconjunctival hemorrhages [Figure 1], bluish to black discoloration of the face and bluish to red discoloration of the neck and upper chest [Figure 2]. There were bruises and surgical emphysema at the neck and upper chest but no bleeding from the nose or the ears. His vital signs were as follows: blood pressure (BP)=110/60mmHg, heart rate (HR)=108 beats/min, respiratory rate (RR)=34 breaths/min, and oxygen saturation on room air was 80%. Auscultation of the chest revealed poor air entry in lungs and scattered crepitation. Heart auscultation was normal and there were no signs of cardiac tamponade. Abdomen was soft but with tenderness in the left upper quadrant and bowel sounds were positive.

A portable cervical spine X-ray was normal. Portable chest X-ray showed bilateral hemopneumothorax and rib fractures on the left side. Two thoracostomy tubes size 32F were inserted one on each side and immediately drained 800ml of blood from the left side and 550ml from the right side. Oxygen therapy was started by nasal cannula, but the patient’s oxygen saturation did not improve. Arterial blood gases showed hypoxia (partial pressure of oxygen (PO2)=43mmHg) and hypercapnia (partial pressure of carbon dioxide (PCO2)=61mmHg) and a pH of 7.27. Thus, the patient was intubated and started on controlled mechanical ventilation at the following settings: a frequency of 18 breaths per minute, tidal volume of 800ml, positive end-expiratory pressure of 5cm H2O, and fraction of inspired oxygen of 80%. A nasogastric tube was also inserted and drained gastric juice. The patient was admitted to the intensive care unit (ICU).

In the ICU, the patient was further evaluated to determine the amount of blood loss and other organs functions. An electrocardiogram and cardiac enzyme studies were assessed to exclude blunt cardiac injury (BCI). While the patient was on mechanical ventilation, the arterial blood gases improved (PO2=100mmHg, PCO2=40mmHg, bicarbonate =23.9mEq/L, oxygen saturation 99%, and pH 7.35).

The radiological and computed tomography (CT) scan examinations of the chest confirmed the above findings in addition to bilateral pulmonary contusions. CT scan of the abdomen was normal and brain CT showed mild brain edema. While the patient was in the ICU, he developed bleeding from the endotracheal tube, which was controlled using tracheobronchial irrigation with cold saline and sodium bicarbonate as well as suctioning. We used fiberoptic bronchoscopy through the endotracheal tube to clear up the thick inspissated bloody secretion and to clarify the cause of the bleeding. The examination of the airway tree showed contused anterior wall of the trachea 2.5cm above the carina [Figure 3]. Ultrasound examination of the abdomen was normal on two follow-up assessments and neither solid organ injury nor intra-abdominal fluid collection were detectable. The patient was evaluated by an ophthalmologist and ENT specialist to rule out any related injuries.

The patient was weaned from the mechanical ventilator after six days, and the right-sided chest tube was removed. Repeated chest X-ray showed expanded lungs, but the left dome of the diaphragm was elevated and the costophrenic angle was blunted with retained blood in the left thoracic cavity [Figure 4]. These findings with the unexplained upper abdominal pain justified performing diagnostic left thoracoscopy, although the CT scan and ultrasound of the abdomen were normal.

The patient underwent left side thoracoscopy and a tear in the diaphragm was found with slight bulging of the fundus of the stomach through the tear without herniation of any abdominal viscera to the thoracic cavity apart from a small piece of omentum. Video-assisted thoracic surgery (VATS) repair of the tear was done immediately using single lung ventilation: two ports (10mm and 5mm) and 3cm utility wound were used to access the left thoracic cavity and the tear was closed with 3/0 prolene interrupted sutures. Retained clotted blood was also removed from the left thoracic cavity by frequent suctioning and irrigation. The size 32F chest tube was left in place. The patient was extubated immediately after surgery and shifted to the thoracic surgery ward. On the second post-operative day, the chest tube was removed after repeated chest X-rays showed a completely expanded left lung. The post-operative period was uneventful. The patient was discharged five days after surgery. He was followed-up in the outpatient clinic for six months and both clinical and radiological examination did not show any significant morbidity.

Discussion

Traumatic asphyxia is described in most of the literature as a rare condition,4,5 caused by sudden compression of the thoracoabdominal region and Valsalva maneuver is necessary for the development of the syndrome.6 Trauma is usually caused by road traffic accidents, compression of the body between two heavy objects, entrapment beneath vehicles where the body is compressed against the ground, or falling in a narrow space.7 It has also been reported to be related to asthma, paroxysmal coughing, protracted vomiting, and jugular venous occlusion.8

It was first described over 170 years ago by Ollivier in his observations on the cadavers of people trampled upon during crowd upheavals in Paris on Bastille Day.9 Later, Perthe’s added some other characteristics such as mental dullness, hyperpyrexia, hemoptysis, tachypnea and “contusion pneumonia” to the initial description.9 The reason why the signs of traumatic asphyxia are confined to the head and upper chest may be due to the fact that the lower part of the body is protected from the elevated venous pressure by a series of valves. Alternatively, increased airway pressure may compress or obliterate the inferior vena cava to protect the lower part of the body.10

In our patient the trauma occurred at work, whereas most published cases followed road traffic accidents.4 The characteristic physical appearance of our patient was the first thing to attract the attention towards the diagnosis of traumatic asphyxia; the importance of an accurate history, paying attention to the mechanism of trauma and a thorough systemic clinical examination are to be stressed.

There was strong evidence of the systemic nature of traumatic asphyxia confirmed by the involvement of different organs in the clinical syndrome without direct involvement by the trauma. In some fatal cases, autopsy findings showed macro- and microscopic changes in the thyroid gland resulting in black thyroid, which may be considered as one feature of the syndrome.11

Treatment of traumatic asphyxia is based on oxygen supplementation and intubation with mechanical ventilation, general supportive measures, as well as dealing with the other associated injuries where the lungs head the list of the affected organs. The outcome is usually good; however, it can lead to significant morbidity and mortality depending on many factors including the age of the patient, the duration of chest compression, the severity of pulmonary injury, and the associated injuries especially those that involve the cardiovascular system and the head, which may be fatal.12

Conclusion

Traumatic asphyxia implies more systemic injuries than just a syndrome and it manifests as unforgettable, striking, and alarming specific physical signs. It could be missed in patients with multiple injuries or when the picture of the presentation is not classical and, hence, it should always be kept in mind in such patients especially when the injury involves a blunt trauma to the chest. Management includes early recognition, general supportive measures, and organ specific treatment. Bronchoscopy should be considered in any case of traumatic asphyxia for both diagnostic and therapeutic purposes.

Disclosure

The authors declared no conflicts of interest. Written informed consent was obtained from the patient for publication of this case report and its accompanying images.

references

1. Eren B, Türkmen N, Fedakar R. An unusual case of thorax compression. J Ayub Med Coll Abbottabad 2008 Jan-Mar;20(1):134-135.
2. Khandhar SJ, Johnson SB, Calhoon JH. Overview of thoracic trauma in the United States. Thorac Surg Clin 2007 Feb;17(1):1-9.
3. Shields MD, Thomas W, LoCicero J, Reed CE, Feins RH. General Thoracic Surgery.7th ed. Philadelphia: Lippincott Williams & Wilkins; 2009. p. 893.
4. Sertaridou E, Papaioannou V, Kouliatsis G, Theodorou V, Pneumatikos I. Traumatic asphyxia due to blunt chest trauma: a case report and literature review. J Med Case Rep 2012;6:257.
5. Eken C, Yıgıt O. Traumatic asphyxia: a rare syndrome in trauma patients. Int J Emerg Med 2009;2(4):255-256.
6. Karamustafaoglu YA, Yavasman I, Tiryaki S, Yoruk Y. Traumatic asphyxia. Int J Emerg Med 2010;3(4):379-380.
7. Byard RW, Wick R, Simpson E, Gilbert JD. The pathological features and circumstances of death of lethal crush/traumatic asphyxia in adults–a 25-year study. Forensic Sci Int 2006 Jun;159(2-3):200-205.
8. Newquist MJ, Sobel RM. Traumatic asphyxia: an indicator of significant pulmonary injury. Am J Emerg Med 1990 May;8(3):212-215.
9. Richards EC, Wallis ND. Asphyxiation: a review. Trauma 2005;7:37-45 .
10. Nishiyama T, Hanaoka K. A traumatic asphyxia in a child. Can J Anaesth 2000 Nov;47(11):1099-1102.
11. Byard RW. Pathological changes in the thyroid gland in crush asphyxia. Forensic Sci Med Pathol 2013 Dec;9(4):568-572.
12. Uzkeser M, Aydin Y, Emet M, Cakir Z, Aslan S, Ozturk G, et al. Traumatic asphyxia: case report. Hong Kong JEmerg Med. 2011;18:339-342.Neurosurg 1997 Dec;87(6):843-850.
